Description

Features:

• Adjustable driver seat: Tool-free adjustment of seat position to quickly set a comfortable driving position.
• Dual headlights: Dual headlights at the front for clear visibility when driving in dark conditions.
• Hour meter: Hour meter for easy control of operating time, service and maintenance intervals.
• Pedal-operated hydrostatic transmission: Easy speed and direction control with pedal-operated hydrostatic transmission. Separate pedals for forward and reverse.
• Compact design: Compact design for effortless navigation in narrow passages and easy storage while not in use.
• Anti-scalp wheels: The cutting deck is equipped with anti-scalp wheels, which reduce the risk of scalping when cutting uneven lawns.
• Ergonomic controls: Comfortable driving position and operation thanks to the adjustable seat and easy-access controls. Spring-assisted cutting height adjustment for easy setting of the desired height.
• ROS in start key: ROS is activated with the start key for quick access to reverse mowing, and to minimise the risk of the function being used unintentionally.
• Manual blade engagement: Lever to engage the cutting deck.
• Fuel level window: The fuel level window makes it easy to check the fuel level.
• Dual pedal drive: Dual pedal drive for better drive control and easy, intuitive operation
• Control levers on one side: Control levers on only one side make it easy to get in and out of the seat on the other side.
• Collection bag: A large bag collects your grass clippings, leaving a clean lawn as a result.
• Towing hook included: Additional functionality thanks to the included towing hook, which enables the use of many accessories.
• Lever-Mounted cutting height adjustment: Easily accessible cutting height adjustment for improved ergonomics. The spring-assisted cutting height adjustment makes setting the desired height even easier.
• Turn-key start: Easy to get operating under any weather condition, and no choking is needed. Just turn the key and go.

Technical Specification:

• Cutting width – 95 cm
• Cutting height max – 105 mm
• Cutting height min – 25 mm
• Nose roller – No
• Anti-scalp wheels – 2
• Drive method – Dual pedal operation
• Speed forward max – 10 km/h
• Speed reverse max – 6 km/h
• Cylinder displacement – 586 cm³
• Engine brand – Husqvarna
• Motor/engine manufacturer – Husqvarna
• Engine name – HV 586AE
• Net power at preset rpm Energy 1) – 11.7 kW
• Net power at preset rpm – 2,800 rpm
• Cylinders – 2
• Power/fuel type – Petrol
• Oil filter – Yes
• Seat material – PU
• Seat type – Standard
• Front-End Protection – Available as an accessory
• Hour meter type – Digital
• Seat back height – Medium
• Steering wheel type – Ergonomic
• Collector – Included
• Transmission type – Hydrostatic
• Transmission Brand – Tuff Torq
• Sound power level, guaranteed (LWA) – 100 dB(A)
• Sound pressure level at operators ear (LpA) – 84 dB(A)
• Exhaust emissions (CO₂ EU V) 2) – 778 g/kWh
• Base machine, height – 110.7 cm
• Base machine, length – 264 cm
• Tyre dimensions, front – 15×6-6
• Tyre dimensions, rear – 18×8,5-8

Disclaimer:

• ¹⁾ Net power at preset rpm Energy: Net power rating as per SAE J1349, at specified RPM as specified by the engine manufacturer
• ²⁾ Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
