Description

Function:

• Blade brake clutch – Electromagnetic
• Optiflow – Yes
• Grass bag dumping – Manual
• Positions and cutting – 7
• Noise value – sound power level (dB(A)) – 100
• Mulching – Optional
• Rear deflector – Optional
• Tow hitch – Optional

Dimensions:

• Length (mm) – 2440
• Width (mm) – 1060
• Height (mm) – 1230
• Dry weight (kg) – 237

Cutting:

• Cutter deck size (cm) – 102
• Number of blades – 2
• Synchro or Asynchro – Synchro
• Height adjustment (mm) – 29-90
• Grass bag capacity (Litres) – 300

Engine:

• Engine 4-stroke – OHC V-twin
• Engine displacement (cc) – 530
• Engine model – GCV530
• Engine Rated Power (kW/rpm) – 9.4/2,800
• Fuel tank capacity (Litres) – 5.4
• Engine oil capacity (Litres) – 1.3
• Transmission type – Variable: Hydrostatic
• Driving speed (km/h) – Progressive 0 to 8.2

Tyres:

• Front tyres (diameter x width – rim) (inches) – 15 x 6.00 – 6
• Rear tyres (diameter x width – rim) (inches) – 18 x 8.50 – 8
• Turning radius (m) – 1.8
