Description

Features:

• A two-piece, ribbed rear roller, provides superior traction, manoeuvrability and avoids turf marking when turning.
• First of its kind Crank-Safe BBC System. Our patented system combines the ease of use of a BBC system with the reassurance of lifetime crank-shaft warranty.**†
• Aluminium cutter deck for increased durability, rigidity and corrosion resistance.
• Easy-wash hose connector allows you to clean the underside of your Harrier® without getting your hands dirty.
• Trim Side means you can cut right to the edge – ideal for around borders raised flower beds and retaining walls.
• Available with a Blade Brake Clutch (BBC) mechanism which stops the cutting blade but keeps the engine running. Ideal when emptying the grass bag or when moving from one lawn to another.**
• Lifetime crank-shaft warranty against bending from accidentally hitting a solid object.†
• High-performance cut and collection system, designed using aerospace technology to ensure class-leading performance in every season.
• Vari-Pitch™ cutting technology automatically adjusts the cutter deck to increase airflow when set to cut longer grass (patent pending).
• ReadyStart® technology. This intelligent system recognises the temperature of the engine and primes the starting process accordingly, ensuring hassle-free starting time after time. (CODE475A and COSE476A only)
• Seven height-of-cut settings between 13-60mm, controlled by a single counter-balanced lever for quick adjustment.
• Folding handlebars reduces the storage space needed.
• Easy to empty – Fabric grass-bag can be lifted through the handlebars

*Annual service required.
**Only available on the Harrier® 48 Auto-Drive VS BBC (CODE475A).
†Applies to the original purchaser.
Refer to the owner’s handbook for full Terms and Conditions.

Technical Specification:

• CUTTER DECK SIZE (CM) – 48
• RECOMMENDED LAWN SIZE§ (M2) – 500m2
• CUTTER DECK MATERIAL – Aluminium
• POWER SOURCE – Petrol
• BRAND & MODEL ENGINE / MOTOR – Briggs & Stratton 650 EXi Series
• ENGINE / MOTOR TYPE – Single cylinder, 4-stroke, air-cooled, OHV, ReadyStart®
• ENGINE POWER RATING (KW) – 2.4kW
• POWER OUTPUT (CC) – 163cc
• CUTTERBLADE SPEED (RPM)* – 2850rpm
• FUEL TYPE – Unleaded
• FUEL TANK CAPACITY (L) – 1.0L
• OIL TYPE – SAE 30
• OIL CAPACITY (L) – 0.45L
• DRIVING SPEED (MPH) – 1.8 – 3.3mph
• BLADE BRAKE CLUTCH (BBC) – Yes
• POSITIONS & HEIGHT OF CUT (MM) – 7 (13 – 60mm)
• REAR ROLLER TYPE & MATERIAL – Two-piece polymer
• GRASS BAG CAPACITY (L) – 70L
• WEIGHT† (KG) – 48kg
• UNFOLDED LENGTH (MM) – 1562mm
• UNFOLDED WIDTH (MM) – 532mm
• UNFOLDED HEIGHT (MM) – 1039mm
• FOLDED LENGTH (MM) – 1275mm
• FOLDED WIDTH (MM) – 530mm
• FOLDED HEIGHT (MM) – 590mm
• FOLDED LENGTH – WITHOUT GRASS BAG (MM) – 935mm
• FOLDED WIDTH – WITHOUT GRASS BAG (MM) – 530mm
• FOLDED HEIGHT- WITHOUT GRASS BAG (MM) – 480mm
• WARRANTY* RESIDENTIAL (YEARS) – 5 Years
• WARRANTY* COMMERCIAL (MONTHS) – 3 months

*Domestic use only, annual service required
†Applies to the original purchaser. Refer to manual for full T&Cs.
‡Patent pending
